With so many great Best Hinge Mortise Jig to pick from, like those from brands such as Milescraft,TREND,Woodhaven,RYOBI, it can be tricky for customers to decide what to buy. But after extensive research, we’ve discovered the stand-out Best Hinge Mortise Jig currently on the market.
Our team rigorously tested numerous products available to consumers. The one that stands at the top of our list is Milescraft Best Hinge Mortise Jig, thanks to its impressive performance and features. Below you’ll find more of our top-rated picks, along with insightful analysis from our seasoned experts. Check out their thoughts before making your purchasing choice. With this guide backing your decision, you’re sure to end up with a Best Hinge Mortise Jig you’ll love.
Editor's Choice
Milescraft 1213 HingeMate300 - Complete Jig for Mortising Door & Jamb Hinges And Latch & Strike
Top 10 Best Hinge Mortise Jig
We researched and compared the top products in the Best Hinge Mortise Jig category to provide you with these recommendations.
1. Milescraft 1213 HingeMate300 - Complete Jig for Mortising Door & Jamb Hinges And Latch & Strike
- Install hinges from 2-1/2in. to 4-1/2in.
- Adjustable cams automatically align templates for 1-3/8in. or 1-3/4in. doors.
- Sturdy steel frame can be mounted on both the door and the jamb
- Durable tungsten carbide 1/2in. router bit cuts clean, level mortises
- Dual-position templates rotate template to achieve 5/8in. or 1/2in. radius mortises
- Centered tabs align the jig on pre marked lines, or hold tape measures for manual positioning
- Easy to use drop in template design with clearly marked templates
- Sturdy steel template frame with door thickness selector knob for 1-3/4 and 1-3/8-Inch doors
- Includes durable tungsten carbide tipped router bit with ball bearing eliminating the need for guide bushings on your router
- Centered tape measure tabs and easy measure guide ensure correct and precise installation of door hardware
- Reusable packaging for template storage when not in use
2. Trend H/JIG/C 2-Piece Hinge Jig Skeleton in Case , Black
- EFFICIENT AND FAST: Built-in guide bush offsets on each hinge block, along with the indexed back set discs, ensure superfast setup and maximum efficiency; An additional 12mm diameter long-reach cutter such as the Trend C019AX1/4TC is required
- VERSATILE USES: Internal or external doors; Frames and linings with rebates or fitted stops up to 25mm thick; The indexing back set positions cover standard 20mm, 25mm and 30mm hinge leaf widths; Easily adjusted for other hinge leaves
- PRECISION ACCURACY: Hinge positions are replicated with pinpoint precision on the door and frame from a single set up for increased productivity on site, or in the workshop for pre-hung door and frame work
- CONVENIENT FOR ANY WORKPLACE: Supplied in a robust carrycase with a 16mm guide bush and securing bradawls, a light duty router such as the Trend T5 is ideal for making the cuts; Ideal for fire work
- INCLUDED: H/JIG/C; 3 x Hinge sliding aperture block assemblies; 4 x Bradawls (short blade); 1 x 16mm guide bush; 1 x Carry case
3. Woodhaven 8536 3-1/2" Hinge Jig - 5/8" Radius
- 3-1/2" Hinge Jig w/5/8" radius corners
- Fastest, easiest, least expensive and most accurate way to cut a hinge mortise. Clamps to work so there's no nail holes or other unsightly blemishes. Jig attaches to a 3/4" wood fence you supply with the included hardware. The fence provides chip-free cuts and easy indexing. Two screw-in indexing pins position the fence to the backset you want and insure it's square on the jig.
- Made of 10mm (.393) thick phenolic for heavy duty use, measures 5-5/8" x 7-5/8".
- Uses a bearing guided bit (our 8500 - sold separetly), or bushing & bit combination (5030K & 13416 - sold separately), to follow the jig for perfect mortises. Router & bit not included.
- Lifetime guarantee against defects in material or workmanship. Made in the USA!
4. Woodhaven 8668 for SOSS 218 Hinge
- 8668 is for a SOSS 218 hinge - 1-1/8" wide x 4-5/8" long shallow mortise. Requires a 1/2" solid carbide upcut spiral bit (15410 or equivalent, sold separately) and a 3/4" Bushing & Locknut (5032 or equivalent, sold separately) to cut the mortises.
- Hinge setback is built-in according to the manufacturers specs.
- Jig clamps to the work (no nail holes) and, using your plunge router, both the long/shallow and short/deep mortises are cut without moving the jig or part. Has two retractable stops for the short/deep mortise.
- Requires a 3/4" OD bushing (our PN 5032K) and a 1/2" spiral upcut bit (our PN 15410), both sold separately. If using your own bushing, make sure the nose isnt over 3/8" long.
- Lifetime guarantee against defects in material or workmanship. Made in the USA!
5. Milescraft 1220 Hinge Mate350 –Complete Hinge Installation Kit-Cut Hinge Mortises on Doors, Jambs,
- Install hinges from 2-1/2in. to 4-1/2in.
- Adjustable cams automatically align templates for 1-3/8in. or 1-3/4in. doors.
- Sturdy steel frame can be mounted on both the door and the jamb
- Durable tungsten carbide 1/2in. router bit cuts clean, level mortises
- Self-centering hinge bit drills perfect pilot holes
6. Ryobi A99HT3 Door Hinge Installation Kit/Mortiser Template
- NO NEED FOR ANY SCREWS OR NAILS thanks to the integrated non-marring clamp that will let this tool fit standard door thicknesses
- CUT FOR ROUNDED OR SQUARED HINGES thanks to the removable plastic insert
- WORKS FOR ALL STANDARD HINGE THICKNESSES AND LENGTHS (1/4 inch or 5/8 inch thickness and 3 to 5 inches in length)
- 3 INCLUDED BITS 1x Carbide Tip Router Bit, 1x Self Centering Hinge Bit, 1x PH2/8-10SL Double Ended Screwdriver Bit
- WORKS WITH BOTH COMPACT AND FULL SIZE ROUTERS
7. PORTER-CABLE Door Hinge Template (59370)
- Quick And Easy Set Up With Lock-In Pins To Ensure Security
- Complete With Double Headed Nails For Easy Removal
- Included Along With The Template Are A High-Speed Mortise Router Bit With Bearing Brads, Instructions
- 8 Hinge Sizes From 2-1/2 Inch To 6 Inch And 5 Door Sizes From 1-3/8 Inch To 2-1/2 Inch
- Quick and easy set up with lock-in pins to ensure security
- Complete with double headed nails for easy removal
- Included along with the template are a high-speed mortiser router bit with bearing brads, instructions
- 8 hinge sizes from 2-1/2 inch to 6 inch and 5 door sizes from 1-3/8 inch to 2-1/2 inch
- Made from Fiberglass, reinforced plastic with extended platform for better router stability
8. Milescraft 1222 Hinge Mate 150 – Door Hinge Installation Kit/Mortiser Template with ½” Router
- Includes 1/2" Ball bearing guided Router bit
- Steel template frame for easy template change out
- Create 3"and 3. 5" hinges with ease
- Package dimension : 8.0" L x 3.13" W x 1.6" H
9. Ryobi A99HT3 Door Hinge Installation Kit/Mortiser Template Bundled with Ryobi A99LM2 Door Latch
- 2 ITEMS INCLUDED - Ryobi Door Hinge Installation Kit and Ryobi Door Latch Installation Kit
- HINGE KIT - 3 INCLUDED BITS WITH BUILT IN STORAGE (carbide tip router bit, self centering hinge bit, PH2/8-10SL double ended screwdriver bit) for routers and screwdrivers, so you can get to work on renovating your home right out of the package
- HINGE KIT - CLAMPS TO STANDARD DOORS thanks to the integrated screw in clamp that will let this tool fit standard door thicknesses
- LATCH KIT - BUILT-IN SCORING AND CHISEL TOOL: This kit will help you minimize the amount of tools you bring to the jobsite
- LATCH KIT - TWO INCLUDED DRIVER BITS: [1x 1-inch PH2 bit] [1x 1-inch SL 8-10 bit]
10. Milescraft 1214 Hingemate200 - Door Hinge Installation Kit for Interior Doors , Black
- Install hinges from 2.5 in. to 4.5in.
- Adjustable cams automatically align templates for 1-3/8 in. or 1.75 in. doors
- Sturdy steel frame can be mounted on both the door and the jamb
- Dual-position templates rotate template to achieve 5/8 in. or 1/2 in. radius mortises
